The USB-2 is a cutting-edge cold asphalt emulsion binder machine from GlobeCore. This high-performance machinery is meant to mix and prepare binders in order to guarantee the end product’s superior quality and longevity.
Modern mixing and emulsification techniques are used by GlobeCore’s USB-2 to guarantee a stable and homogenous mixture. It is the perfect option for usage on building sites and asphalt factories due to its lightweight and portable nature.
The USB-2’s key benefits are its excellent performance, dependability, and longevity. Because of the high-quality materials used in its construction, the device will last a long time and require little maintenance. Simple operation eliminates the need for sophisticated technical knowledge and enables the rapid and effective synthesis of binders from cold asphalt emulsion.
Cold asphalt emulsion binder machine USB-2 Specifications
| Specification of bitumen equipment | Value |
| Maximum production capacity (preparation time included), m3/hour | 8 * |
| Minimum bitumen consumption, m3/hour | 10.5 |
| Water consumption, m3/hour | 5–7 * |
| Flux consumption, dm3/hour | 50–250 * |
| Acid consumption, dm3/hour | 50–150 * |
| Emulsifier consumption, dm3/hour | 50 * |
| Max bitumen input pressure, MPa | 0,2 |
| Bitumen to mixer pressure, MPa | 1.4 |
| Water phase to mixer pressure, MPa | 0.2 |
| Bitumen input temperature, °С | 140–160 |
| Water input temperautre, °С | 40–60 |
| Max emulsion output head, m | 10 |
| Max nominal power, kW | 33 |
| Power voltage at 50 Hz, V | 380/220 |
| Dimensions (L/W/H), mm | 4500/2250/1800 |
| Max weight, kg | 1800 |
* Depending on process recipe
